Model: 10-60L
This classic series of commercial dough mixers is built for bakeries, pizzerias, and food production facilities that demand durability and consistent performance. Available in six bowl capacities 10-60L. Constructed from stainless steel for long-lasting hygiene and strength. Choose between silver or white finish. Each model features CE certification, a variable frequency drive (VFD) with reverse function, providing smooth starting, adjustable speed, and easy dough release. The powerful motor and robust transmission deliver sustained power for heavy daily use. Ideal for mixing bread dough, pizza dough, pastry, and more.
Shift-on-the-Fly™ 功能可在电机运转时方便、高效地切换速度，无需停止再重启机器。
Full stainless steel bowl and frame resist corrosion, withstand heavy use, and meet commercial kitchen sanitation standards. Easy to clean and built to last.
VFD technology provides soft start, reduces energy consumption, and allows stepless speed adjustment. Protects the motor and extends equipment life.
One‑touch reverse rotation helps release dough from the hook without stopping the machine, saving time and reducing operator effort during batch processing.
Motors ranging from 0.55kW to 2.2kW, combined with precision gear drives, handle stiff doughs batch after batch. Engineered for continuous operation in busy bakeries.
| 参数 | 10L | 20L | 30L | 40L | 50L | 60L |
|---|---|---|---|---|---|---|
| Volt | 220V | 220V | 220/380V | 220/380V | 220/380V | 220/380V |
| Frequency | 50Hz | 50Hz | 50Hz | 50Hz | 50Hz | 50Hz |
| Shaft Speed(r/min) | 165 | 110/220 | 110/220 | 110/220 | 110/220 | 110/220 |
| Bowl Speed(r/min) | 15 | 8/16 | 8/16 | 8/16 | 8/16 | 8/16 |
| Power | 0.55kW | 0.75kW | 1.1kW | 2.2kW | 2.2kW | 2.2kW |
| Bowl Capacity | 10L | 21L | 35L | 40L | 50L | 64L |
| Max Flour Capacity | 5kg | 8kg | 13kg | 16kg | 20kg | 25kg |
| N.w(KG) | 62 | 69 | 83 | 120 | 125 | 150 |
| G.w(KG) | 77 | 89 | 105 | 148 | 152 | 170 |
| Product Size(mm) | 650*340*720 | 670*390*750 | 760*430*780 | 860*480*940 | 930*530*940 | 930*530*940 |
| Package Size(mm) | 760*380*850 | 800*440*870 | 830*470*890 | 930*520*1020 | 980*550*1030 | 1020*590*1070 |
